ADAM Audio T5V Active Studio Monitor – Pair
₹60,800.00 Original price was: ₹60,800.00.₹51,490.00Current price is: ₹51,490.00.
2 in stock
With its 5” woofer the bass-frequency response of the T5V extends to 45 Hz. The new U-ART tweeter, a breakthrough solution for use in high-resolution recording and mixing on a budget, goes up to 25 kHz and is mated to a precision waveguide with the same dispersion-control attributes as the High Frequency Propagation (HPS) waveguide used in ADAM Audio’s flagship S Series monitors. The waveguide’s highly uniform dispersion of high frequencies provides an incredibly wide sweet spot that frees you from being glued to a rigid mix position while working.
A beveled cabinet with a rear-firing bass reflex port and a small footprint allows placement anywhere in your room, no matter how small, and contains built-in DSP-controlled driver crossovers and equalization as well as multi-way analog connections. Powered with a 50 W Class D amplifier for the woofer and a 20 W Class D amplifier for the U-ART tweeter, the T5V produces SPLs of up to 106 dB per pair. Excellent acoustic characteristics, small dimensions and an outstanding cost/performance ratio make this studio monitor perfectly suited for use in small control rooms in music, video and broadcast production.
U-ART 1.9” Accelerated Ribbon Tweeter
- Allows longer operation with fewer signs of fatigue
- Their breakup is prevented by the folded diaphragms, distortions are effectively reduced to a minimum
- Advanced dynamic range due to acoustically effective diaphragm surface that is 2.5 times bigger (compared to a classic tweeter according to the piston principle)
The air velocity ratio of 4:1 during the sound generation by folded U-ART membrane
- Direct, fast response in the high-range even with complex transients
HPS waveguide from the S Series
- Makes dispersion more consistent and imaging more stable over a wider area
- Reduction of early reflections on the surfaces of, e.g. mixing consoles, desks, etc.
Lightweight polypropylene construction of the woofer
- Excellent transient response even at high sound levels without breakup of the diaphragm
Vertical 2-way system with 5” woofer
- High resolution of the stereo image
Spacious rear-firing bass reflex port
- Bass reproduction with very low compression
Linear frequency response of 45 Hz to 25 kHz
- Unbiased reproduction in a wide frequency band
Maximum peak sound pressure per pair in 1 m ≥ 106 dB
- Powerful, compression-free sound reproduction even at very high sound levels
DSP-powered crossover design
- Smooth frequency response without interferences between the drivers in the critical mid-range
Simple room acoustic adjustments via high- and low-shelf filters
- Allows optimal adaptation to acoustically difficult listening environments or individual preferences
Analog inputs over XLR and RCA
- Optimized for balanced and unbalanced line signals
Acoustically optimized cabinet geometry
- Reduction of unwanted reflections on the cabinets
Compact cabinet dimensions
- Fits every desktop
Specification
Powered | Yes |
Power Configuration | Bi-amped |
LF Driver Size | 5" woofer |
LF Driver Type | Polypropylene |
HF Driver Size | 1.9" U-ART tweeter |
LF Driver Power Amp | 50W |
HF Driver Power Amp | 20W |
Frequency Response | 45Hz-25kHz |
Crossover Frequency | 3000Hz |
Maximum Peak SPL | ≥106dB SPL @ 1m |
Input Types | 1 x XLR, 1 x RCA |
Enclosure Type | Rear ported |
Height | 11.7" |
Width | 7" |
Depth | 11.7" |
Weight | 12.6 lbs. |
