Hollyland Pyro 7 Wireless Transmitter & Receiver And 7 Inch Monitor, 3-in-1,1300ft (400m) Los Range and 0.06s Latency, Auto Dual-Band Hopping (ADH),Solo Kit
Original price was: ₹60,000.00.₹49,990.00Current price is: ₹49,990.00.
3 in stock
Pyro 7 is a 7-inch wireless monitor that integrates the functionalities of TX, RX, and monitor, all in one. It utilizes Auto Dual-Band Hopping (ADH) technology. With 1,300ft (400m) and an incredibly low latency of only 60ms, Pyro 7 supports 2.4GHz/5GHz dual-band transmission and automatic frequency hopping. Its exceptional hardware design enables Pyro 7 to simultaneously connect one transmitter to four receivers, and the convenience of dual-camera monitoring is achieved through customizable shortcut keys. Additionally, the upgraded HollyOS system provides enhanced image analysis capabilities and allows for video file export via an external SD card. Pyro 7 is compatible with Pyro H and Pyro S, which means you can easily pair Pyro 7 with either Pyro H or Pyro S. This provides you with greater flexibility and scalability to meet various monitoring needs.
HD Mode
Optimal for superior image quality. HD Mode guarantees clear visuals, maintaining a stable bitrate of 8-12 Mbps even at a range of 1,300ft (400m).
Smooth Mode
The bitrate dynamically adjusts in this mode to achieve the lowest 60ms latency for ultra-long-distance transmission.
Dual Boosts.
Less Latency and More Stability.
Compared to traditional video transmission systems whose range extends at the cost of image quality and latency, Pyro S excels with increased transmission distance while preserving video quality and minimizing latency.
ADH
Auto Dual-Band Hopping
With our developed Auto Dual-Band Hopping (ADH) technology, Pyro 7 operates on both 2.4 GHz and 5 GHz dual-bands and features intelligent Auto Frequency Hopping, so it can automatically choose the clearest channel. This feature guarantees reliable and uninterrupted wireless video transmission.
Dual Band
2.4 GHz & 5 GHz.
Pyro 7 offers a dual-band transmission solution that addresses common issues such as signal interference, low transmission efficiency, and frequency congestion. And the omnidirectional high-gain antennas will also ensure stable signals in all directions. This provides better signal transmission performance and efficiency. With Pyro 7, you won’t have to worry about video drop issues any more.
Intelligent
Auto Frequency Hopping
Pyro 7 is equipped with Auto Frequency Hopping technology, which constantly scans and monitors the strength of the signal and interference across various frequency ranges to find the best wireless channel to use, resulting in a more reliable connection.
KEY FEATURES
- 1TX & 4RX (1 Monitor in box)
- 1300ft (400m) & 0.06s Latency
- 4 GHz & 5 GHz Dual Band
- Auto Frequency Hopping
- TX, RX, and Monitor – All in One
- Dual-View Quick Monitoring Switch
- 7-Inch & 1200 nits
- Precise Image Analysis
- SDI & HDMI Loopout
- RTMP Streaming
| Items | Parameter |
| Input Port | HDMI 1.4b + 3G SDI |
| Output Port | HDMI 1.4b + 3G SDI |
| HDMI 1.4b + 3G SDI | RP-SMA Male*2 |
| Power Input | DC Input (2.0mm core socket) |
| Headphone Jack | 3.5mm |
| Upgrade Port | USB-C (USB 2.0 OTG) SD Card Slot |
| Screen Size | 7" Touchscreen |
| Screen Resolution | 1920 × 1200 pixels |
| Pixel Density | 323 PPI |
| Aspect Ratio | 16:9 |
| Screen Brightness | 1200 nits |
| Contrast Ratio | 1000:1 |
| Power Input Voltage | 10 - 18V/2.5A DC Input (nominal 12V) |
| Power Consumption | < 22W |
| Net Weight | 545g (19.2oz) with battery plate included and external antennas excluded |
| Dimensions (L × W × H) | 180 × 127 × 31.8mm (7.1" × 5" × 1.25") with battery plate and external antennas excluded |
| Operating Frequency | 5.1 - 5.8 GHz; 2.412 - 2.484 GHz |
| Transmit Power | ≤ 23 dBm |
| Receiver Sensitivity | -80 dBm |
| Display Latency | < 50ms |
| Transmission Latency | ≈ 60ms (test data when 1080p60 signals are transmitted in a laboratory) |
| LOS Range | •1,300ft (400m)* (Connection to the monitoring app may affect the range); •650ft (200m)* (in Broadcast mode) |
| Bandwidth | 20 MHz; 40 MHz (in Broadcast mode) |
| Audio Format | HDMI 1.4b 8-Channel |
| Operating Temperature | - 10℃ - 45℃ |
| Storage Temperature | - 40℃ - 60℃ |
| HDMI Input 720p50/59.94/60 1080i50/59.94/60 1080p23.98/24/25/29.97/30 1080p50/59.94/60 3840*2160 23.98/24/25/29.97/30 | HDMI Loopout 720p50/59.94/60 1080i50/59.94/60 1080p23.98/24/25/29.97/30 1080p50/59.94/60 3840*2160 23.98/24/25/29.97/30 SDI Loopout 720p50/60 1080i50/60 1080p24/25/30 1080p 50/60 1920*1080 24/25/30 HDMI/SDI Output 720p50/60 1080i50/60 1080p24/25/30 1080p 50/60 1920*1080 24/25/30 |
